Independent and almost residue-free emptying of barrels and containers

NEMO® barrel emptying systems are versatile and suction themselves towards the bottom of the barrel. With NETZSCH emptying systems, you can empty your barrels and containers in the chemical, pharmaceutical and food industries almost wholly.

The heart of the system is a NEMO® BY progressing cavity pump, which provides you with constant, low-pulsation pumping. The versatility is enormous: From low-viscosity to barely flowing media, with or without solids content, shear-sensitive, sticky or abrasive, with the progressing cavity pump, you can pump even complex media gently and independently of pressure and viscosity fluctuations.

Optionally, the pump can also be heated. This enables you to pump products that tend to harden or require temperature control. When the system is switched on, a vacuum forms under the follower plate. At the same time, this exerts a slight pre-pressure on the medium to ensure constant suction. This ensures emptying with a residual quantity of less than one percent of the total content. In this way, you save medium and, consequently, money.

Capacities Range

• Flow rate : approx. 6 ml/min to 10 m³/h
• Barrel size : Barrels between 20 l to 200 l as standard
• Clean emptying, residue without inliner < 1 %.
• Max Pressure : 24 bar

Advantages

• Gentle conveyance
• Low pulsation
• Significantly lower shear rate than other pump technologies
• Smooth transport of media with solids
• Conveyance independent of temperature and viscosity
• Complete discharge, residues < 1 %
• Easy maintenance
• Low life cycle cost
• Stainless steel, easy to clean
