Economical Dedusting Solution in Absence of Compressed Air

For venting applications in absence of compressed air, the DUSTSHAKE R03 filter represents a reliable cost-effective solution.

The DUSTSHAKE R03 Dust Collector has been designed for installation on top of bins or silos, which are pneumatically filled by tankers. DUSTSHAKE R03 has a polygonal casing and square bottom flange. It contains a vertically mounted multi-pocket filter element, which is intermittently cleaned by an electric shaker. A hinged top cover made of steel allows easy, quick, user-friendly maintenance.

Function :

• Dust is separated from the dirty air flow by means of a multi-pocket filter element. An electric shaker, which is fixed laterally on the bottom of the casing, shakes the filter ele­ment at intervals to remove the dust from the media. The dust drops back into the silo, bin or hopper.
• Shaker cleaning may only be operated after pneumatic filling has been terminated.
• DUSTSHAKE R03 is designed for venting applications only.

Features :

• Filter surface: 17 m² (183 sq ft)
• Air volume: 1,500 m³/h (883 cfm)
• Multi-pocket filter element
• Mechanical shaker cleaning
• Hinged top cover for quick filter element replacement
• Removable front panel for comfortable inspection of filter media
• Easy to install

Benefits :

• No compressed air required (mains supply only)
• User and maintenance-friendly design
• Reliable and durable
• Suitable for outdoor installation
