PS Single Impact Pneumatic Hammers

MARTSHOCK PS Single Impact Pneumatic Hammers produce a shockwave generated by a single impact of an internal piston on the metallic base welded on the , or wall. This action is particularly efficient if the powder at issue tends to pack under pressure or stick to the or wall. Moreover, MARTSHOCK PS is an efficient solution against bridging or rat-holing problems.

MARTSHOCK PS Single Impact Pneumatic Hammers are particularly suitable retrofitting existing cones or hoppers since of the or drilling of the wall is not required. Operation should be intermittent at a pressure ranging from 3 to 6 bar (44 ~ 87 PSI). When operating multiple hammers, those at the bottom should be activated first, moving progressively upwards at regular intervals to the remaining ones.

Benefits :

  • Compact design with integrated valve
  • High performance
  • Easy installation
  • Suitable for potentially explosive environments (ATEX-compliant)

MARTSHOCK PS robust design is suitable both outdoor indoor application. External body parts are manufactured from galvanized steel POM. MARTSHOCK PS are supplied with a mounting plate, which has to be welded on the or wall, as well as a safety chain preventing accidental dropping during installation or maintenance. To satisfy all market demands MARTSHOCK PS is available in three different sizes.
