CHEM LS Series (High Pressure Fan)

Developed to handle heavy corrosive fumes, vapours, contaminated air and aggressive gases at high pressure. Casing of thermoplastic such as PP, PE, PVC, PVDF etc. and can be also of GRP (Vinyl ester Grade) FRP. Impeller of thermoplastic can be blended with composites to overcoming high temperature, flame retardant resistant, ultraviolet or Electrostatic Discharge protection. The radial tip Backward Curve Impeller is statically and dynamically balanced in accordance with Grade G2.5 of BS 5625 Part 1 (1979). Tested and rated in accordance with BSI and AMCA standards. Noise accordance to DIN 45635.

Operating Range :

  • Maximum CMH: 300,000
  • Maximum Static Pressure: 8,000Pa
  • Maximum Temperature: 80° C
  • Fan Sizes: 160mm to 1120mm

Applications :

  • pulp and paper
  • wastewater-treatment
  • fertilizer
  • pharmaceutical
  • metal plating
  • laboratory fume hoods
  • small plating and pickling operations
  • etching processes
  • chemical-fume scrubbers
  • soil remediation

Options :

  • Coat fan base
  • Flanged outlet
  • Drain
  • Belt guard
  • Motor and drive canopy
  • Flex connector
  • A/9 Motor and drive mounting
  • Flanged inlet
  • Flanged gasket
  • Access door
  • Shaft seal
  • Transition
  • Spark resistant construction

  • CHEM LS 5 to 41 PP

    opt_FSIP

Features

  • Centrifugal fans, radial blade and radial tip wheel designs
  • Smooth PP reduces friction and minimizes solids build-up
  • Polypropylene composition impervious to extreme outside environments
  • Performance data is the result of testing in accordance with AMCA standard test codes


  • 9.CHEM LS Series (High Pa Fan)
